NOTICE:
The rock mucking loading machine is all operated by operating buttons. Control buttons corresponding to the same coordinates are placed on the front and rear control boxes. The mucking loading machine driver can operate on either side of the left or right control box in accordance with the premise of the specific work site.
When the mucking loading machine is loading the rock, the driver holds the armrest on the control box with both hands, and the thumbs of both hands press the control button next to the armrest as required. The swing of the bucket to the left and right is when the bucket is lowered.
When the mucking loading machine bucket is promoted, it rotates to the median coordinate to start unloading, all of which are operated by the driver by hand.
Before loading the rock, first stop the rock loader at a place about 1-1.5 meters away from the schist pile, lower the bucket to the lowest coordinate, and then press the "travel" button to start the rock mucking loading machine forward until the bucket is inserted The bottom of the schist pile is only. In order to fill the bucket better, while the bucket is inserted into the schist pile, press the "promotion" button briefly to make the promotion motor continue to start to make the bucket shake, and at the same time, continue to press the "travel" button , So that the rock loader continues to move, so as to better fill the bucket.
After the bucket is filled with schist, press the "promotion" button to start the promotion idea to promote the bucket, and unload the loaded schist into the mine truck. After the bucket is unloaded, use the recoil effect of the buffer spring and the bucket Its own weight automatically falls to the original lowest coordinate.
After the bucket is unloaded, the tunnel mucking machine driver presses the "return" button to retract the rock loader to a distance of 1-1.5 meters from the schist pile, and then carry out the mucking loading machine to the above operating procedures.
